Views & cameras

The Camera panel holds every camera concern in three tabs: Compose authors how the scene arrives, Views keeps the named cameras you save, and Studio renders imagery from them.

Step 1/7

Camera work happens in the scene editor, in the same scene the published viewer will serve.

Views & saved cameras
Step 1 of 7
  1. Camera work happens in the scene editor, in the same scene the published viewer will serve.
  2. One panel holds every camera concern: composing the arrival, the named cameras you save, and the studio output made from them.
  3. The opening camera decides how the scene first arrives for a visitor. It is the frame that gives the first impression.
  4. Zoom limits keep the product presentable: the shopper cannot push through the surface or drift so far that the product becomes a dot.
  5. The pose is the exact numbers behind the frame, with position and look target. It can be copied, so a framing you like can be reproduced.
  6. Saved cameras are named framings you author once and reuse everywhere.
  7. Saved cameras are the pool everything else draws from: the opening camera is chosen from this list, and studio output renders it shot by shot.
  • Opening camera: which saved camera the scene arrives on. This is the frame that carries your first impression, so choose it deliberately rather than leaving it to wherever you last orbited.
  • Opening style: the motion of that arrival. Choose Gentle Dolly, Arc Reveal, Zoom Out Reveal, Crane, Wide Sweep, or No Motion for a static cut. Preview opening camera replays it exactly as a visitor will see it.
  • Near / far limits: capture the current distance as the closest or furthest the visitor may travel, so nobody ends up inside the product or loses it in the distance.
  • Camera pose: numeric position and look target for the working camera, with Reset camera to return to it.

Saved cameras are named framings. Frame the shot, name it and save it. The same list feeds everything else, so a shot list and an arrival never drift apart:

  • The opening camera is picked from this list. The entry marked START is the one currently in use.
  • Studio output renders these cameras as repeatable product shots and 360° video.

Apply view, the eye icon on each row, moves the working camera to that saved camera and marks it ACTIVE. Check a shot there before you update it from the current view, rename it or delete it.

Name them as shot names (Hero 3-4, Detail stitching) rather than Camera 3, so the output set documents itself.

A configurable product adds a second camera system on top: per-part cameras that fly the view to whatever the shopper is currently configuring. See Configurator cameras.
