Picker modes & presentation

The picker is the option panel shoppers use in the published viewer and embeds. Its style is a per-product setting.

Step 1/5

The picker is the option panel shoppers use in the published viewer and embeds. Its style is a per-product setting.

Picker modes & presentation
Step 1 of 5
  1. The picker is the option panel shoppers use in the published viewer and embeds. Its style is a per-product setting.
  2. The style switch is in the configurator settings.
  3. Off is the List style, with every part open at once and the camera fixed. On collapses parts into a menu and flies the camera to each part as it opens.
  4. Shoppers read the Picker title, so the part can stay body_v2 while the shopper sees Finish.
  5. A part needs 2+ variations to show a picker. Long palettes show four swatches plus a “+N” tile that opens the full palette.

List (default): every part is shown open at once, with all options visible. The camera stays put while shoppers explore. Best for products with a handful of parts, where the full range is visible at a glance.

Camera focus: parts collapse into a menu, and opening a part flies the camera to that part’s recorded angle. Best for larger assemblies where a flat list would be long, and for products whose parts benefit from being looked at while configured. Record a camera per part for the focus to move. Parts without one keep the current view (see Cameras).

  • Parts appear with labeled swatches, which are colour discs or texture thumbnails with the variation name.
  • Each part’s heading is its Picker title. Set it in the part’s panel when your internal part name isn’t what shoppers should read (e.g. part body_v2, title Finish). Empty means the part name is used.
  • A part needs 2+ variations to show a picker: single-variation parts are fixed elements and stay out of the panel.
  • Long palettes stay short: a part with more than five options shows its first four plus a “+N” tile. Tapping the tile opens the full palette on its own page (back button on top). Picks made there apply to the model instantly. N counts only the options currently offered, so rules that hide options shrink it automatically.
  • Parts driven by a link group are auto-hidden (the driver represents them) unless you turn on their Show in picker toggle. Alternatives collapse into their visibility group’s switch.
  • An option that opens or closes the product carries a state switch. When the selected variation drives a Toggle (open / close) animation, a two-position switch appears under that option. It is labelled with the variation and reads Open / Close, so the shopper sees the current state instead of guessing what a second tap would do. It disappears when a variation that does not move is picked, and its position is read from the model, so it stays correct after a swap or a deep link. See Animations & triggers.
  • A View summary action lists the full current configuration, with prices when your page pushes them in.
  • On plans with Custom Branding, the panel and the summary’s main actions take your brand colour, and your logo sits in the top-left corner of the stage. Text on the brand colour switches between white and black to stay readable. Both come from your workspace branding.

To embed into your own storefront without the built-in controls, turn the picker off and render your own UI. The engine keeps running underneath. See Build your own UI.
